Ports 24×1000Mbps ports (RJ45)+2×1000Mbps Fiber(SFP) ports+2G Combo ports
Standards IEEE802.3, IEEE802.3u, IEEE802.3z,IEEE802.3ab, IEEE802.3x
Switching capacity 56Gbps
Forwarding performance 41.66Mpps
Packet Buffer 4Mbit
MAC 8K
Dimensions (W×D×H) 440*208*44mm
Weight 3.650000 hours
Operating temperature 0°C-40°C (32°F-104°F)
Operating humidity 10%～90% (noncondensing)
Storage humidity 5%～90% (noncondensing)
Indicatorlight PWR:
Death: switch does not power on
Permanent: the switch is powered on
LINK/ACT:
Death: not connected to the network equipment
Green light: connected to 1000Mbps devices
Blinking:connected devices are data transmission
System:
Blinking: the system works
Out: the system is starting or has nopower
